书架箱系列

Mini

桌面与近场聆听的号角小品，细节灵动。

Specifications · 技术参数

Mini 完整技术规格

参数项目	规格值
箱体材质 / Material	Single-Wiring gold plated
板材厚度 / Thickness	19mm / 0,75"
内部结构 / Internal Bracing	No
Cross over chamber	No
频率响应 / Frequency range	60Hz - 20kHz ± 2dB
Bass Cabinet	Bass reflex
Porting	Rear
低音单元 / Woofer	100mm / 4"
Cross over frequency	6000 Hz
Midhigh	Dome
Horn Throat	—
振膜尺寸 / Membrane dimensions	25mm / 1"
Max power input	60 W RMS
效率 / Efficiency	88dB
阻抗 / Impedance	6 Ohm
Impedance linearization	No
Terminal	Single-Wiring
Feets	No
尺寸（高×宽×深） / Dimensions	280 x140 x270 mm 11 x 5,5 x 10,5 in
重量 / Weight	5 kg
Packaging dimensions	45 x 45 x 42 cm
Loudspeakers per carton	2
Packaging weight	12 kg
Center Loudspeakers	—
Standard Veneers	Walnut
Special Veneers	Dark Walnut, White Opaque, Black Opaque
Premium Veneers	On demand
